Key features
- 10 A test current for protective earth resistance
- 0.2 A test current for protective earth resistance
- Loop/line impedance measurement up to 440 V
- Display of short circuit current (PSC)
- Insulation measurement with 250 V to 500 V test voltage
- Residual voltage measurement; display of discharge voltage/time
- Integrated high-voltage test (can be deactivated via key switch)
- Machinery tester in accordance with EN 60204-1
Measuring functions
- Measurement of protective earth resistance
- Loop/Line impedance measurement
- Insulation resistance measurement
- Residual voltage measurement
- High-voltage test
Downloads
| Filename | Date | Size | |
|---|---|---|---|
| MT-204 Product brochure | 2024-05-31 | 2 MB | Download |
| MT-204 User Manual | 2024-06-20 | 2 MB | Download |
| MT-204 Software | 2024-06-20 | 2 MB | Download |
| MT-204 Software User Manual | 2024-03-20 | 0 MB | Coming Soon |
